Thinkpad X60,X60s,T60出世了.

quaino

www.pc.ibm.com/ww/thinkpad/x-t.html

Napa平台,双核处理器.更轻,更节电.


www.notebookreview.com/default.asp?newsID=2701

Lenovo's Newest ThinkPads Unplug the Need for Power Cords from Dawn to Dusk

New ThinkPads Run Up to 11 Hours with Extended BatteryEmbedded Wireless WAN Enables 3G Network Connection on the Road


RALEIGH, N.C., January 5, 2006 - Lenovo today introduced two new ThinkPad models that bring a new level of performance and portability to the world’s most recognizable notebook brand, extending the battery life of its notebook computers to up to 11 hours with an extended battery. (3)

Designed around Intel® Centrino® Duo mobile technology, the ThinkPad X60 Series and ThinkPad T60 Series help business users move further away from the office, connecting remotely with embedded wireless wide area network (WWAN) antennas and operating longer without a power cord. ThinkPad X60 Series and T60 Series draw less power than previous X and T models for extended battery life – improving battery performance in some models by as much as 37 percent.

Intel dual-core processors improve productivity and multitasking versus previous processors, allowing users to run multiple high-performance applications – such as medical or engineering software, virus scan or system backups – that might otherwise paralyze the PC.

"Our customers want systems that are easy to use and allow them to be productive in any location – whether that's in the office, at home, in an airport or at a hotel," said Peter Hortensius, senior vice president, Notebook Business Unit, Lenovo. "These new ThinkPad notebooks merge one of Lenovo's hallmarks – productivity technology – in new thin and light designs to give users improved performance in whatever environment they work."

Portability with a Punch
Select models of upcoming ThinkPad T60 Series and X60 Series notebooks will feature integrated high speed wireless support for VerizonWireless in the U.S. Models supporting the Verizon Wireless BroadbandAccess network are planned to be available in the first-half of this year. Notebooks featuring integrated WWAN antennas enable users to connect to high-speed broadband networks without separately purchased PC cards.

The ThinkPad was the first non-rugged notebook ever to integrate a 3G WWAN antenna for Verizon Wireless BroadbandAccess, which averages download speeds between 400-700 kilobytes per second (kbps). (1) All models feature a hardware switch to manually disable the system's wireless antenna.

In order to help simplify the connectivity process, ThinkVantage Access Connections 4.1 helps mobile users set up and automatically switch from one available network connection to the next, helping reduce costly help desk calls for assistance in changing IP settings, defining default printers or accessing a wireless network.(2) In addition to facilitating wireless peer-to-peer networking, Access Connections 4.1 supports wired, WLAN and WWAN connectivity.

Fresh Out of the Box 24/7
Lenovo's new System Rejuvenation technology — part of Rescue and Recovery — gets rid of the accumulated waste on the hard drive that hampers system performance and makes a system run slow. By cleaning out unused and unnecessary files and getting rid of spyware and adware, Rescue and Recovery can improve system performance and help a PC run faster.

Performance and Portability in One
With the new Intel Centrino Duo mobile technology, including the Intel® Core™ Duo processor and the Intel® Mobile 945 Express Chipset, the ThinkPad X60 Series offers increased performance with 667 MHz front side bus and 667 MHz DDR2 SDRAM. With a 37 percent power-use reduction from earlier platforms used in X Series models, the ThinkPad X60s features the longest standard battery life of any ThinkPad, allowing for up to 11 hours of computing.(3)

The ThinkPad T60 measures an inch thin with a travel weight of 4.8 lbs(4), giving it newfound power and performance in a thin-and-light form factor. For mobile workers, the ThinkPad T60 Series includes a more durable system design, coupling the ThinkPad Roll Cage – an inner armor chassis – with its airbag-like Active Protection System and ThinkPad shock-mounted hard drive.(5)

One Million Fingerprints and Counting
Combining Lenovo's hardware- and software-based security solution and integrated fingerprint reader, select models of the ThinkPad X60 Series and T60 Series are the most secure PCs available today.(6) ThinkPads with integrated fingerprint readers make security simple, enabling users to access password-protected personal and financial information, Web sites, documents and e-mail with a swipe of their finger while helping to protect data from unauthorized access. The integrated fingerprint reader is part of a broad set of security tools offered by Lenovo on select systems that include Client Security Solution 6.0 software and an embedded security chip. In December, Lenovo sold its 1,000,000th ThinkPad with integrated fingerprint reader, making the company the largest provider of biometric-enabled PCs in the world.

Pricing and Availability
The ThinkPad T60 Series and X60 Series can be purchased beginning today on www.lenovo.com, with availability beginning in February. Lenovo personal computers are also available through select business partners. Prices for the ThinkPad T60 Series start at $2049.(7) Prices for the ThinkPad X60 Series start at $1899.(7)

About Lenovo
Lenovo (HKSE: 992)(ADR: LNVGY) is the world's most innovative personal computing company, with a business model built on innovation, operational excellence, customer satisfaction and a focus on investment in emerging markets. Formed by Lenovo Group's acquisition of the former IBM Personal Computing Division, the company develops, manufactures and markets reliable, high-quality, secure, and easy-to-use technology products and services worldwide. Lenovo has major research centers in Yamato, Japan; Beijing, Shanghai and Shenzhen, China; and Raleigh, North Carolina. For more information about Lenovo, visit www.lenovo.com.

Notes
(1) Verizon Wireless Service Speed: Speed averages 400-700 kbps based on network tests with 5 MB FTP data files, without compression. Speed declines with distance from cell site and is limited to 1.54 Mbps at certain cell sites with backhaul limitations. Number of users on the Verizon Wireless data network may also affect maximum possible speed. Average upload speeds expected to be between 60-80 Kbps. Actual speeds and coverage may vary.
(2) Network availability and security will vary by network provider; additional connection charges may apply
(3) When combining the standard 8-cell high-capacity battery with the optional X60 Extended Life battery.
(4) Weight includes standard battery and may vary due to vendor components, manufacturing process and options.
(5) Available on select models.
(6) ThinkPad notebooks with ThinkVantage Client Security Solution and integrated fingerprint reader (available on select models only) can be configured to build in an extra layer of protection for your passwords and documents. No one offers stronger security as a standard feature.
(7) Prices do not include tax or shipping and are subject to change without notice. Reseller prices may vary. Price does not include all advertised features.

Press Contact:
Jeff Dudash
Lenovo, Public Relations
919-395-0617

[ 本帖最后由 quaino 于 2006-1-18 12:34 编辑 ]

lhynh

价钱呢？

quaino

才发布没几天,还没在国内大规模上市呢!说是网上可以订了.
我看过.中国的Lenovo还没看到产品,不过美国的LENOVO到时可以订了.

ThinkPad T60 Series start at $2049.(7)
Prices for the ThinkPad X60 Series start at $1899.(7)

[ 本帖最后由 quaino 于 2006-1-18 12:42 编辑 ]

silver

Prices for the ThinkPad T60 Series start at $2049.(7) Prices for the ThinkPad X60 Series start at $1899.(7)

quaino

ThinkPad X60  17065KU New!
$1,999.00*

Microsoft Windows XP Professional
512 MB
60 GB
Intel® Core Duo processor T2400 1.83GHz
12.1"
1024x768
Intel Graphics Media Accelerator 950
weight 3.62-3.66 lb
Three years parts and labor (system battery: one year)
Integrated Intel PRO/1000 Gigabit Ethernet
56K V.92 designed modem
Intel PRO/Wireless 3945ABG
Fingerprint Reader Client Security Solution

xian_zyc

看美元的价格，也不算贵！但不知到了中国会是什么样一个天价！

quaino

ThinkPad X60s  17023QU New!
$2,099.00*

Microsoft Windows XP Professional
512 MB
60 GB
Intel® Core Duo processor L2400 1.66GHz
12.1"
1024x768
Intel Graphics Media Accelerator 950
3.46-3.51 lb
Three years parts and labor (system battery: one year)
Integrated Intel PRO/1000 Gigabit Ethernet
56K V.92 designed modem
Intel PRO/Wireless 3945ABG
Fingerprint Reader Client Security Solution

quaino

ThinkPad T60 195144U New!
$2,049.00*

Intel Centrino Mobile Technology
Microsoft Windows XP Professional
512 MB
60 GB
Intel® Core Duo processor T2400 1.83GHz
14.1"
1024x768
Intel Graphics Media Accelerator 950
4.65-5.08 lb
UltraNav
Ultrabay Slim

Three years parts and labor (system battery: one year)
Integrated Intel PRO/1000 Gigabit Ethernet
56K V.92 designed modem
Intel PRO/Wireless 3945ABG
Fingerprint Reader Client Security Solution

quaino

转自:http://www.51nb.com/forum/viewthread.php?tid=323296
Lenovo 发布Tinkpad T60(图片)
联想今天正是发布更轻更瘦的thinkpad T60笔记本电脑.T60 继承了T43设计的成功之处,搭载了最新的

intel双核移动cpu.但是其前端的斜面设计,已经与t43大不相同.
T60的具体配置如下:
处理器:采用最新发布的dual core双核芯处理器,目前消息已经证实,其直接搭载了双核处理器而跳过了

单核平台.
显示屏: 提供14.1" xga和14.1sxga+两种分辨率处理器和15.1"的xga和sxga+处理器,预计T60P将会搭载

uxga的15.1屏幕,但是现在还未公布相应型号.
硬盘:采用2.5寸 SATA硬盘,有40,60,80,100G可供选择,同时提供100G的7200转硬盘
内存: 采用ddr2 667外频内存,256M到1G不同容量. 最大支持4G内存,比原来T43 增加一倍
光驱: 和T43一样,提供COMBO和RAMBO供选择
显卡: 将分为三类:一类是提供给不需要强劲显卡性能的商业用户,搭载intel 950显卡;一类是搭载ATI

X1300显卡,高端机型搭载ati x1500显卡,明显优于t43的显卡芯片
继承通信设备:包括猫,G兆网卡,Verizon EVDO WWWAN (optional),以及兰牙
无线网卡: 搭载ThinkPad 11a/b/g II 或者Intel PRO Wireless 3945ABG 网卡 802.11 a/b/g
电池:搭载标准6cell电池或者加强9cell电池
端口:配备了3个usb 2.0接口,红外口,视频输出等,比T43系列多配备了一个usb口,但是还是没有配备1394
尺寸: 对于14.1寸的t60,三围尺寸是12.2*10.0*(1.0-1.2)英寸
15.1'寸的t60,三围尺寸是13"*10.6*(1.2-1.4)英寸
重量: 14.1: 2.17kg/2.34kg
保护: 安全气囊, ThinkPad Shock Mounted Hard Drive, ThinkPad Magneisum Roll Cage
系统: winxp fro
[1]从左侧图片可以看出,风扇位置由原来的T4x系列的中部,移到上部;除了保留了原来t4x系列的猫,网卡以及音频接口外,把视频输出接口从t4x的后测,放到了此位置,另外在下部保留了一个立式usb2.0接口
[2]右侧可以看到,除了光驱外,还在原来t4x的视频输出接口位置,变成了两个usb接口.
[3]后测可以看到,取消了打印机并口,同时增加了散热口.输入电压调整到了20V
[4]键盘布局和Z60系列相近,增加了F8和F10的功能键.access ibm 变成了thinkvatage.但是左下脚还是预留 了IBM的logo.同时增加了win键.这是ibm历史上第一次增加win键.abaxter于05/01/2006 公布该消息.(图片和部分资料来源于notebookreview,在此对abaxter表示感谢)
-------------------------------------------------------------------------------------------------------------------------------

点评一下T60的创新点

[1]USB口从2个扩展刀3个,而且2个放置刀右侧,方便右撇子使用鼠标
[2]显卡比t43 有长足进步,128M的x1300和256M的X1500提供强大性能
[3]硬盘终于实现了完全的串口硬盘,提高整体性能
[4]加如了thinkpad的T系列历史上第一个win键.
[5]Verizon EVDO WWWAN (optional),无线设备
[6]更安全的硬盘防护安全气囊, ThinkPad Shock Mounted Hard Drive, ThinkPad Magneisum Roll Cage
----------------------------------------------------
市场发售型号介绍
ThinkPad T60
Model: 195144G
SN: UD044GE
Prozessor:
Intel® Core Duo processor T2400
1,83 GHz, 667 MHz FSB

Arbeitsspeicher:
512MB ; PC2-5300 DDR2 SDRAM
(max. 2048 MB, 1 Slot frei)

Festplatte:
60 STA-100

Display:
14" TFT-Farbdisplay 1.024 x 768

Grafikkarte:
Intel Graphics Media Accelerator 950

Laufwerke:
CD-RW/DVD-ROM Combo
24X/24X/24X/8X Max EIDE

Netzwerk/Kommunikation:
56K V.92 Modem,
Integrated Intel PRO/1000 Gigabit Ethernet
Intel PRO/Wireless 3945ABG, WCDMA, HSDPA

Schnittstellen:
Docking/Port Replicator
DVI
External Display
Headphone / Line out
Microphone / Line in
RJ-11
RJ-45
3 USB 2.0

Akku:
6 Cell Lithium-Ion Akku mit bis zu 3,4 Stunden Betriebsdauer

Größe und Gewicht:
3,6 cm x 33 cm x 27 cm 2,11 Kg


联想在05/01/2006宣布了thinkpad x60(s)系列超便携和轻薄的笔记本电脑系列.X60系列将采用最新的

intel 移动芯片组,x60替代原来的x32,纤细的x60s替代原来的x41系列.
X60s系列要比x60系列轻薄,因为本质上,联想所做的就是延续X30和x40系列的产品线,整合成x60系列.相

对轻薄的x60系列用在结尾加一个s(slim的英文缩写)来把二者区分开来.X60系列不同与x40系列,它采用

了2.5英寸的普通硬盘,这样更易于升级和提升性能.
处理器: X60系列采用普通电压版的intel 双核处理器,x60s采用低电压版的intel双核处理器
屏幕尺寸: 12.1' xga分辨率
硬盘: 2.5寸 40/60/80/100G 5400转或7200转硬盘,这也是首次在x系列采用7200转的硬盘产品.
显示芯片: Intel Graphics Media Accelerator 950 ,无论是x60还是x60s,都将采用集成显卡.x系列独

立显卡的历史最终结束了内存:采用256m或者512m/1G Pc2-5300/667mhz内存,最大内存支持3GB.由此看来,还是预留了一个内存槽

可以让用户自己添加内存
继承通信设备:包括猫,G兆网卡,Verizon EVDO WWWAN (optional),以及兰牙
无线网卡: 搭载ThinkPad 11a/b/g II 或者Intel PRO Wireless 3945ABG 网卡 802.11 a/b/g
电池:标准4cell电池或者8cell扩展电池,电池续航时间7.9小时,比x41和x32长32%.
端口: 3个usb 2.0;一个ieee1394端口;显示器输出端口,耳机,扩展槽等
Slots: 1 Type II PC Card slot with 34mm Express Card via adapter, 1 Secure Digital card

slot
三围尺寸:
X60: 10.5" x 8.3" x .83 - 1.39" (width x depth x thickness)
X60s: 10.5" x 8.3" x .83 - 1.11" (width x depth x thickness)
携带6cell电池的旅行重量:
X60 - starting at 3.22lbs (比X32轻了11%)
X60s - starting at 2.54lbs (日版) or 2.69lbs (其余全球) (比x41轻了7%)
总的看来,虽然采用2.5寸硬盘的x60比x41厚,但是重量控制的还是比较好的.
通过标准2.5英寸硬盘和3个usb口的布局,改善了原来x4x系列硬盘升级困难,性能相对受到硬盘制约的瓶

颈.左侧端口主要是一个usb和视频输出端口,一个网卡端口和SD卡读卡器以及一个1 Type II PC Card slot

with 34mm Express Card via adapter.
右侧端口布局是两个usb端口和一个1394,还有一个电话线拨号上网端口和电源输入端口,可以看到输入

电压已经升高到20v.
键盘上增加了win键,去掉了access ibm,增加了thinkvatage.
abaxter于05/01/2006 公布该消息.(图片和部分资料来源于notebookreview,在此对abaxter表示感谢)
---------------------------------------------------------------------------------------
(Edited by thinkpadfan)
ThinkPad X60
Modell: 17023QG
SN: UK03QGE
Prozessor:
Intel? Core Duo processor L2400
1,66 GHz; 677 MHz FSB

Arbeitsspeicher:
512MB (max. 2 GB) PC2-5300 DDR2 SDRAM

Festplatte:
60 SATA-100

Display:
12" TFT 1.024 x 769 XGA

Grafikkarte:
Intel Graphics Media Accelerator 950

Netzwerk/Kommunikation:
56K V.92 Modem,
Integrated Intel PRO 000 Gigabit,
Intel PRO Wireless 3945ABG
Bluetooth

Schnittstellen:
Docking/Port Replicator
External Microphone/Line-In
Headphone / Line out
Infrarot
IEEE 1394 (Firewire)
RJ-11
RJ-45
Speaker
3 USB 2.0

Akku:
8 Cell Lithium-Ion Akku mit bis zu 8 Std. Betriebsdauer

Gr??e und Gewicht:
2,0 cm x 26,8 cm x 21,1 cm 1,57 Kg

---------------------------------------
ThinkPad X60s Modell: 170255G SN: UK055GE
Prozessor:
Intel? Core Duo processor L2400
1,66 GHz; 677 MHz FSB

Arbeitsspeicher:
512MB (max. 2 GB) PC2-5300 DDR2 SDRAM

Festplatte:
80 SATA-100

Display:
12" TFT 1.024 x 769 XGA

Grafikkarte:
Intel Graphics Media Accelerator 950

Netzwerk/Kommunikation:
56K V.92 Modem,
Integrated Intel PRO 000 Gigabit,
Intel PRO Wireless 3945ABG
Bluetooth

Schnittstellen:
Docking/Port Replicator
External Microphone/Line-In
Headphone / Line out
Infrarot
IEEE 1394 (Firewire)
RJ-11
RJ-45
Speaker
3 USB 2.0

Akku:
4 Cell Lithium-Ion Akku mit bis zu 3 Std. Betriebsdauer

Gr??e und Gewicht:
2,0 cm x 26,8 cm x 21,1 cm 1,13 Kg

printemps

quaino

http://digi.163.com/06/0110/10/273ND4N500161MAH.html
[新品] 比T43更到位 NAPA新小黑多图爆料
网易数码报道 http://digi.163.com
日期:2006-01-10 10:41:20　来源: pcpop(北京)　　　　　　网友评论 1 条　进入数码论坛

quaino

移动双核时代 第三代迅驰平台
2006-01-09 15:01:39 太平洋电脑网

　　2003年1月9日，Intel正式发布了新一代迅驰移动技术平台－－Carmel；2005年1月19日Intel发布了第二代移动迅驰技术平台－－Sonoma；今天，2006年1月9日，Intel发布第三代移动迅驰技术平台－－Napa。简单地说，Napa是Intel第三代移动技术平台的名称，它由Intel 945系列芯片组、Yonah Pentium M处理器、Intel 3945ABG无线网卡模块组成的整合平台，相对于我们已经非常熟悉的第二代迅驰Sonoma平台最大的技术提升有，系统总线速率提升到667MHz，Yonah处理器推出单、双核技术并且采用65nm制程，Intel Pro/Wireless 3945ABG无线模块则开始兼容802.11a/b/g三种网络环境。其中，Yonah Pentium M处理器开始引入双核技术，是这次Napa发布的一项重点技术。
　　Yonah Pentium M处理器

　　在Napa平台里面，最为消费者所瞩目的莫过于采用了双核技术的Yonah Pentium M处理器， Yonah Pentium M处理器是采用65nm制程新一代移动处理器，不过仍然采用Socket 479针脚。它除了引入双核技术以外，同时前端总线速率提升至667MHz，因为双核心的存在而使用的SmartCache技术、新一代电源管理技术，以及开始支持SEE3多媒体指令集。

　　Yonah Pentium M双核是Intel第一款在移动处理器产品里面引入双核技术的产品，它在一个处理器里面植入了两个核心单元，通过SmartCache技术共享2M L2二级缓存，根据处理任务的负荷程度，在两个核心处理单元之间进行协调，然后分别同时进行指令运算，从而达到更高效的处理能力。双核技术所解决的是，并发多任务运行时整体的性能。

　　虽然Yonah双核Pentium M有两个核心，但是缓存是通过SmartCache技术来共享使用2M L2缓存，而并没有为两个核心单独设计二级缓存，因此总线速率同时提高至667MHz会相应减少处理器与芯片组之间通信存在瓶颈的可能性。

　　双核心技术的引入，虽然性能方面获得了绝对的提升，同时也提高了多任务并发运行的处理效率，但是作移动处理器产品来说，功耗有没有得到相应的控制也是消费者最为关心的方面。Yonah Pentium M处理器的产品线当中，单核Yonah处理器的功耗还是与Dothan处理器一样，而双核Yonah普通版的最大运行功率达到了31W，超低电压双核Yonah Pentium M只有9W，低电压单核15W，普通单核为27W，分别看看在Napa平台里面各个芯片的最大功耗值：

芯片类型 最大功耗值
Yonah 双核  31W
Yonah 单核 27W
Yonah 低电压 15W
Yonah 超低电压双核 9W
Yonah 超低电压单核 5.5W
Calistoga 945GM  7W
Calistoga 945PM  6W
Calistoga 945GMS  5.5-6W
ICH7-M 1.7-1.9W
3945ABG 1.35w

　　处理器的功耗比相应Dothan处理器保持同样的水平，而双核版的Pentium M处理器的功耗则有所提升，因此Intel引入了名为Intel Dynamic Power Coordination技术、Enhanced Intel Deeper Sleep节能技术，来使Napa平台可以更合理的根据用户的应用来调整功耗，结合Intel SPeedstep自动调频技术，Napa平台在整体功耗方面会相应到改善。

　　 Intel Digital Media Boost也是Yonah处理器引入的一个新技术，其主要就是在SSE/SSE2 Micro Ops Fusion、SSE解码器容量提高以及对SSE3指令集的支持，这一技术的引入，会增加Yonah处理器在多媒体应用方面的性能，对于家庭用户来说，其娱乐性会得到改善，比如在视频剪辑、视频播放等应用上，性能以及效果都会得到提高。

　　Intel 945芯片组系列

　　Calistoga是移动Intel 945系列芯片组的代号，相比于Intel 915系列芯片组，Calistoga芯片组提供了系统总线至667MHz，支持DDR2双通道内存，最高速率支持667MHz（PC5300），支持PCI-Express x16接口技术，Intel 945GM集成Intel Graphics Media Accelerator 950显示单元，400MHz显示核心，并且提升共享系统DDR2 667MHz内存为显存。

　　Intel 945北桥相应地搭配ICH7-M南桥，支持6个PCI-Express x1接口，同时也支持PCI接口，SATA-300硬盘接口，最高支持3Gbps传输速率。另外，同样支持HD Audio音频技术。

　　有一个比较为消费者关心的是，Intel GMA950集成显卡是否能够支持Microsoft即将正式推出的Windows Vista操作系统？经过安装测试，在集成Intel GMA950显示单元的Napa平台上仍然没有办法开启Vista精致的玻璃边框效果，以及各种特效。

　　Intel Pro/Wireless 3945ABG无线模块

　　Napa将使用Intel Pro/Wireless 3945ABG无线模块，它支持IEEE 802.11a/b/g无线网络协议，并且在Napa中将一改在Sonoma以及之前的Carmel平台使用的PCI接口，开始使用PCI-Express x1接口，并且模块的规格也转为一种更小的迷你卡。

　　基于PCI-Express x1接口的WiFi迷你卡无疑最大的好处可以为机器节约一些资源，符合笔记本电脑机体尺寸向更便携的方向发展，不过就目前来看，也有部分Napa平台的工程样机仍然采用基于PCI接口的Intel 2200BG无线模块，因此在未来Napa产品中，这两种无线模块会同时存在，需要一个过渡期来完成两代无线模块的交接。

　　兼容802.11a/b/g三种无线网络协议，可以使Napa有更为广泛的应用领域，就随着迅驰技术发展起来的无线网络市场来看，目前普遍的还是兼容802.11b/g双模无线环境，而抗干扰能力更强的802.11a无线环境多用于一些特殊领域。


太平洋电脑网

zhp0427

新品上市叫的都很凶的

肖宁买本本

E文太差了，看不下去……帮顶

mark

很想知道水货什么时候能有？

samsary

什么时候能买到
